Dijital Manometre tek sensör girişli el tipi GHM 5130
Dijital Manometre tek sensör girişli el tipi GHM 5130
HIGHLIGHTS:
- Up to 1000 measurements per second
- Large double display with background illumination
- Sensors calibrated and fully exchangeable
- incl. calibration protocol
- Connection for GMSD sensors
- Waterproof
GENERAL:
This handheld instrument is a valuable tool for demanding pressure measurements. Extremely robust plug connections, the silicone protection cover, backlight and a waterproof design allow its usage in harsh industrial and field environments.
APPLICATIONS:
- Industry and craft, HVAC: heating, ventilation, air conditioning
- Leakage test / pressure test
- Chimney draft measurement: under pressure, leakage test at buildings (ie 4 Pascal test)
- Measurements of gas and oil firings
- Automobile trade, hydraulic analysis (peak pressure)
Specifications: GMH 5130
Sensor connections: 1
Suitable probes: GMSD / MSD sensors, available ranges (resolutions) from -1.999 ... 2.500 mbar (0.001 mbar) to 0 ... 1000 bar (1 bar)
Display range max.: -19999 ... +19999 digit
Display unit: * depends on measuring range selection and sensor:
mbar, bar, Pa, kPa, MPa, mmHg, inHg, PSI, mH2O
Measuring frequency: 4 measurements / s or 1000 measurements / s with peak value memory
Average filter: adjustable: 1 ... 120 s
Accuracy: ±0.1 % FS ±1 digit
Connections
Sensor: 1 x 7-pole bayonet connector
Output /external supply: 4-pole bayonet connector for serial interface, supply (with accessories: USB adapter USB 5100)
Display: 4 ½ digit 7-segment, illuminated (white)
Operating conditions: -25 ... +50 °C, 0 ... 95 % RH (non-condensing)
Storage temperature: -25 ... +70 °C
Power supply: 2 x AAA-battery, battery life 500 h (without illumination, 4 measurings / s)
Housing: impact resistant ABS housing with pop-up clip
Protection class: IP65 / IP67
Dimensions: 160 x 86 x 37 mm (H x W x D) incl. silicone protection cover (red)
Weight: approx. 250 g incl. battery and protection cover
Scope of supply: Device, battery, calibration protocol, manual
